Lens specifications:
80mm achromatic doublet, 40mm diameter
Focus adjustment:
+3 diopter to -4 diopter nominal
Interocular adjustment:
Not required for the given lens diameter
Type of illumination:
2 x 12 Volt, 10 Watt halogen lamps, colour corrected, with flashed opal glass diffuser
Materials:
3mm and 6mm MDF board glued, and finished in hammer tone enamel
Formats supported:
External slide dimensions 132mm x 80mm; aperture dimensions up to 53 x 53 mm
Description of viewer:
An in-depth description and construction comments about this viewer are located at http://werple.net.au/~kiewavly/MFvwr.html
Are these viewers for sale?:
Not for sale
Availability of plans:
Plans located at http://werple.net.au/~kiewavly/Misc/6x6vwr.gif
